The strength and durability that racing demands at an economical price. Forged rods are sized and finished in the U.S.A. and fitted with ARP 7/16", 190,000 PSI cap screw bolts (some include ARP L-19, 265,000 PSI bolts). Rods feature precision alignment sleeves to positively locate the rod cap, ensuring big end bore size and eliminating cap walk. Sold in weight-matched sets of eight, unless specified.
- Length Center to Center (in.):
- 5.137 in.
- Beam Style:
- H-beam
- Material:
- Forged 4340 steel
- Finish:
- Shot-peened
- Wrist Pin Style:
- Floating
- Pin End Bore Diameter:
- 0.905 in.
- Pin End Width (in.):
- 0.842 in.
- Rod Journal Diameter (in.):
- 2.047 in.
- Big End Bore Diameter (in.):
- 2.1650 in.
- Big End Width (in.):
- 0.842 in.
- Connecting Rod Bolt Diameter:
- 3/8 in.
- Connecting Rod Bolt Brand:
- ARP
- Rod Bolt Material:
- ARP2000 alloy
- Fastener Tensile Strength (psi):
- 200,000 psi
- Connecting Rod Bolt Head Style:
- 12-point
- Cap Retention Style:
- Cap screw
- Weight Matched Set:
- N/A
- Approximate Weight (g):
- 530
- Magnafluxed:
- N/A
- Clearanced for Stroker:
- No
- Advertised Horsepower Rating:
- N/A
- Advertised RPM Rating:
- N/A
- Quantity:
- Sold as a set of 4.
- Make:
- Subaru
- Engine Family:
- Subaru EJ
