LS Water Pump Spacer Kit is used for mounting 1998-02 LS1 Camaro (or GTO any year) water pumps onto LS Truck/SUV (any year) engines to keep the belt aligned. This is the EXACT dimension required for this combination.
The package includes: 2 spacers, 4 gaskets, 1 steam port plug (1/8"), and bolts.
LS Series Engine Belt Spacing Guide: Corvette, G8, SS, & CTSV engines have the tightest belt to block setting (other than FWD vehicles w/ LS4) LS1 Camaro belt spacing is approximately .86" further outboard Truck & Camaro 2010up belt spacing is approximately .71" further than LS1 Camaro (1.57" from Corvette)
Note: always use the belt tensioner that would have originally came with the water pump that you are using. (example: 1998-02 Camaro water pump would use a 1998-02 Camaro belt tensioner) These spacers will keep the alignment perfectly.
Features- Water Pump Spacer Material:
- Billet aluminum
- Water Pump Spacer Finish:
- Natural
- Water Pump Spacer Thickness (in.):
- 0.700
- Hardware Included:
- Yes
- Gaskets Included:
- Yes
- O-Rings Included:
- No
- Quantity:
- Sold as a kit.
- Notes:
- Designed for mounting a 1998-2002 LS1 Camaro water pump to an LS truck engine block.
- Make:
- Chevrolet
- Engine Family:
- Chevy small block Gen III/IV (LS-based engines)
- Engine Sizes:
- 4.8L/294, 5.3L/325, 6.0L/364
- Years:
- 1999-2019
