- This oil pan spacer kit contains a right and left billet aluminum spacers, mounting hardware that is included in Moroso Part No. 20144 Dart LS Next Oil Pan Kit
- This spacer kit is designed to mount the following GM LS oil pans*; Moroso, O.E.M. or other aftermarket oil pans to DART LS Next engine blocks
- Billet Aluminum Spacers have a built in oil ring groove on the side that mounts between the spacer and the engine block, on the other side of the spacer is a smooth surface that oil pan gasket mounts between it and the oil pan
- Includes mounting hardware, billet aluminum spacers have mounting holes for A/C and P/S brackets
*Any oil pan besides Moroso Part Nos. 20144 or 20151 will require modification to itself or the oiling system
PART NO. | AVAILABLE OPTIONS |
93152 | Oil Pan Gasket, GM LS Series (Except LS7 & LS9) |
24890 | GM LS Oil Pump Flange Reinforcement |
Emissions Warning
Products sold on this website may not be legal for use on public roads or highways due to Environmental Protection Agency (EPA) restrictions or California Air Resources Board (CARB) emissions regulations. Federal and State regulations may restrict Product installation to pre-emissions regulation (Model Year 1974 or earlier) or to competition/racing vehicles used exclusively in
1) events organized by recognized bodies, authorizing permits for participating drivers.
2) racing event qualification, and3) practice associated with events.
Installation of such products, including driving racing vehicles to and from the track, may be considered illegal “tampering ” or as “defeat device”, and may result in federal and state penalties. It is the purchaser’s responsibility to ensure compliance with all applicable emissions laws, including California’s stricter standards.
Proposition 65 Warning:
This product may contain chemicals known to the state of California to cause cancer, birth defects, or other reproductive harm. For more information, visit www.P65Warnings.ca.gov.
- Oil Pan Replacement Component Type:
- Spacers
- Quantity:
- Sold as a pair.
- Notes:
- Designed to fit Dart LS Next engine blocks.
