Fits: 1968-'72 Nova, 1965-'72 Chevelle, 1967-'69 Camaro
Can also be used in additional applications check dimensions for clearance.
Oil Pan, Steel, Clear Zinc, Steel, Wet Sump, 7 Quart Capacity, 6" deep, Baffled
Engine Application: GM LS Series
Features
- Trap-door baffling for improved oil control
- Clears 4.25" stroke with most steel rods and can be used with Moroso Nos. 22941 & 22943 Windage Tray
- Two -10AN fitting for remote filter installation
- Use stock dipstick
| PART NO. | RECOMMENDED PICKUPS |
| 24050 | Fits: Stock or Moroso GM LS Oil Pump Nos. 22119, 22120, 22121 & 22122 |
| PART NO. | AVAILABLE OPTIONS |
| 22119 | Oil Pump GM LS, Standard Volume & Pressure |
| 22120 | Oil Pump GM LS, Race |
| 22121 | Oil Pump GM LS High Volume & Pressure |
| 22122 | Oil Pump GM LS Standard Volume/High Pressure |
| 22941 | Windage Tray, GM Studs |
| 22943 | Windage Tray, ARP Studs |
| 24890 | GM LS Oil Pump Flange Reinforcement |
| 38306 | Bolt Kit, Oil Pump, 5 Bolts, GM LS |
| 38541 | Oil Pan Stud Kit |
| 71162 | Dust Shield for Moroso and Aftermarket Oil Pans |
| 93152 | Oil Pan Gasket, One Piece Design, Steel Reinforced, GM LS Series (Except LS7 & LS9) |
| 97315 | O-Ring, GM LS Oil Pump Pick Ups, 2 Pack |
| 25030 | GM LS Rear Oil Passage Plug, Billet Aluminum, Two O-rings |
- Rear Main Seal Style:
- 1-piece
- Sump Style:
- Wet
- Stroker Clearanced:
- Yes
- Dipstick Provision:
- No
- Dipstick Included:
- No
- Maximum Stroke with OE Rod:
- 4.125 in.
- Dipstick Location:
- N/A
- Sump Location:
- Rear
- Oil Pan Capacity:
- 7.00 quarts
- Oil Pan Depth (in.):
- 6.000 in.
- Oil Pan Material:
- Steel
- Oil Pan Finish:
- Clear zinc
- Baffled:
- Yes
- Kicked Out:
- Yes
- Kickout Position:
- N/A
- Windage Tray Included:
- No
- Pickup Included:
- No
- Oil Pump Included:
- No
- Oil Pump Driveshaft Included:
- No
- Crank Scraper Included:
- No
- Drain Plug Thread Size:
- 1/2 in.-20
- Gaskets Included:
- No
- Hardware Included:
- No
- Quantity:
- Sold individually.
- Notes:
- Designed for GM LS engines only. Uses stock dipstick. Can also be used in additional applications, check dimensions for clearance.
- Make:
- Chevrolet
- Engine Family:
- Chevy small block Gen III/IV (LS-based engines)
- Engine Sizes:
- 5.7L/350
- Years:
- 1965-1972
