Louvered design allows oil thrown from the rotating assembly to drain into the sump without splashing back, reducing windage, increasing horsepower and cutting down on oil temperature. Manufactured from 16 gauge steel. Mounts right to the main caps with the customer supplied ARP Main Stud Kits
Fits Moroso Oil Pan Nos. 20139, 20140, 20141, 20142, 20143, 20145, 20147, 20148, 20149, 20150, 21150, 21152, 21153, 21157 and 21158
Must use Corvette C-6 Dipstick and tube Part Nos. 12570788 & 12570787
- Windage Tray Style:
- Louvered
- Sump Location:
- Rear
- Sump Style:
- Wet
- Stroker Clearanced:
- No
- Crank Scraper Included:
- No
- Trimming Required:
- No
- Windage Tray Material:
- Steel
- Windage Tray Finish:
- Natural
- Hardware Included:
- No
- Installation Kit Required:
- Yes
- Quantity:
- Sold individually.
- Notes:
- Must be used with Corvette C6 oil dipstick and ARP main stud kit.
- Make:
- Chevrolet
- Engine Family:
- Chevy small block Gen III/IV (LS-based engines)
- Engine Sizes:
- 4.8L/294-7.0L/427
- Years:
- 1997-2017
