Steel, Wet Sump, 5.5 Quart Capacity, 5-1/16" deep
Engine Application: Acura VTEC, Non-VTEC and Honda 1.6L B16A3
- Removable anti-slosh baffle, six trap doors and two sump baffles for improved oil control
- 1/2" N.P.T. turbo/supercharger drain back and 1/2" N.P.T. temperature sender provisions
- Steel with clear zinc finish
- Kickout for additional capacity
- Works with OEM exhaust manifold and most aftermarket exhaust/header combinations
- Use stock Oil Pump & Pickup
| PART NO. | AVAILABLE OPTIONS |
| 38366 | Oil Pan Stud Kit |
| 93200 | Oil Pan Gasket, One Piece Design, Acura/Honda B Series |
| 22206 | B Series, Oil Pump |
- Sump Style:
- Wet
- Oil Pan Style:
- Street/Strip
- Sump Location:
- Driver side
- Oil Pan Capacity:
- 5.50 quarts
- Stroker Clearanced:
- No
- Dipstick Provision:
- No
- Dipstick Included:
- No
- Oil Pan Depth (in.):
- 6.000 in.
- Material:
- Steel
- Finish:
- Clear zinc
- Baffled:
- Yes
- Kicked Out:
- Yes
- Windage Tray Included:
- No
- Pickup Included:
- No
- Oil Pump Included:
- No
- Oil Pump Driveshaft Included:
- No
- Crank Scraper Included:
- No
- Drain Plug Thread Size:
- 1/2 in.-20
- Gaskets Included:
- No
- Hardware Included:
- No
- Quantity:
- Sold individually.
- Notes:
- Includes one 1/2 NPT bungs for plumbing turbo oil return line and oil temperature sender.
